Sfera (With mast) Mobile Wrapping Machine

Sfera (With mast) Mobile Wrapping Machine

Mytho (With Arm) Stretch Film Wrapping MachineLybra Auto Stretch Film Wrapping Machine
Category:

Starting as a low-cost model the SFERA can grow with the needs of your business. Providing real value for money, it is guaranteed to be the best value packaging machine equipped with a pre-stretch film system.

If you decide to buy the model with FM carriage this can easily be upgraded to our power pre-stretch system, which can be supplied with either ONE or TWO Motors depending on your requirements.

The easy to use 11″ TOUCH SCREEN operating panel allows you to setup a number of different parameters, these ensure the best quality wrapping patterns.
Our enhanced version PLC provides up to 99 programs suitable for every kind of wrapping pattern for differing and varied products. This machine is ready for pallet wrapping in the 21st century.

Description

Technical Characteristics
Wrapping programs model SFERA EASYOperating panel 11″ TOUCH with 6+1 Programs
Wrapping programs model SFERAOperating panel 11″ TOUCH with 99 Programs
Min pallet dimension650 x 400 mm
Max pallet dimensionPallet size can be programmed on the operating panel
Adjustable speed facilitated by frequency changerMax 65 m/min
Carriage braking systemFM (FTL=Force to load)
Standard wrapping height2200 mm
Optional wrapping height2700 / 3000 / 3500 mm
Photocell detection of load heightSTANDARD SUPPLY
Adjustable Spool carriage speed facilitated by inverterFrom 1,3 up to 5,4 m/min
Upwards Spool carriage speedIndependently settable
Downwards Spool carriage speedIndependently settable
Lifting with fork lift truckSTANDARD SUPPLY
Total installed power0,55 Kw
High frequency built-in battery charger230 V – 50/60 Hz
Standard charging voltage230 V – 50/60 Hz – 1 Ph
Operating voltage24 V
Electrical and motor protection systemIP 20
Output capacity35 Pallets per Hour **
* Depending on configuration
** Depending on film quality and working environmentWrapping conditions and pallet dimensions have an influence on the Max output capacity
Stretch film specifications
Recommended thickness for stretch-filmFrom 10 to 35 µm
Available options
Magnetic brake system FEX – FE (FTL = Magnetic brake force to load)
Power Pre-Stretch One Motor PRSX (Included gears 150% / 200% / 250%)
Power Pre-Stretch Two Motors PSX
Roping systemX
Precise stopping at cycle endX (With Geo Kompass)
